40尺高柜集装箱内尺寸（集装箱的内尺寸）

2024-09-02 05:15:51 来源：用户：

大家好,小东方来为大家解答以上的问题。40尺高柜集装箱内尺寸，集装箱的内尺寸这个很多人还不知道,现在让我们一起来看看吧！

1、外部尺寸如下: 20GP:6058mm(L)X2438mm(W)X2591mm(H)40GP:12192mm(L)X2438mm(W)X2591mm(H)40HC:12192mm(L)X2438mm(W)X2896mm(H) 45HC:13716mm(L)X2438mm(W)X2896mm(H) 53HC: 16154mm(L)X2438mm(W)X2896mm(H) 20RF: 6058mm(L)X2438mm(W)X2591mm(H)40RF:12192mm(L)X2438mm(W)X2591mm(H)40RH:12192mm(L)X2438mm(W)X2896mm(H) 20OT:6058mm(L)X2438mm(W)X2591mm(H)40OT:12192mm(L)X2438mm(W)X2591mm(H) 20FR:6058mm(L)X2438mm(W)X2591mm(H)40FR:12192mm(L)X2438mm(W)X2591mm(H) 内部尺寸如下: 20GP:5898mm(L)X2352mm(W)X2393mm(H) Door opening: 2280mm (H) X 2340mm (W)40GP:12032mm(L)X2352mm(W)X2393mm(H) Door opening: 2280mm (H) X 2340mm (W)40HC:12032mm(L)X2352mm(W)X2698mm(H) Door opening: 2585mm (H) X 2340mm (W)45HC:13556mm(L)X2352mm(W)X2698mm(H) Door opening: 2585mm (H) X 2340mm (W)53HC: 15994mm(L)X2352mm(W)X2698mm(H)Door opening: 2585mm (H) X 2340mm (W)20RF: 5452mm(L)X2290mm(W)X2237mm(H) Door opening: 2875mm (H) X 2290mm (W)40RF:11586mm(L)X2290mm(W)X2237mm(H)Door opening: 2875mm (H) X 2290mm (W)40RH:11586mm(L)X2290mm(W)X2542mm(H) Door opening: 2570mm (H) X 2290mm (W)20OT: 5895mm(L)X2350mm(W)X2351mm(H) Door opening: 2279mm (H) X 2342mm (W)40OT:12028mm(L)X2350mm(W)X2351mm(H)Door opening: 2279mm (H) X 2342mm (W)20FR: 5920mm(L)X2227mm(W)X2233mm(H) 框架箱没门40FR:12054mm(L)X2227mm(W)X1955mm(H) 框架箱没门。

本文到此分享完毕，希望对大家有所帮助。
